Application:

China Weichai 6200, 8200 Marine diesel engine cooling sea water pump ZFCW80-65-200 Cast iron Marine diesel engine cooling sea water pump, single stage impeller,self-priming pump,it can be applied to Chongqing Weichai 6200 marine diesel engine heat exchanger cooling water circulating. Used for Shipping, Fishing boat, Shipbuilding, Engine host matching,Wash deck, Fire fighting, etc.

China Weichai 6200, 8200 Marine diesel engine cooling sea water pump ZFCW80-65-200 Cast iron Marine diesel engine cooling sea water pump is single stage impeller,single suction, cantilevered centrifugal pump, corrosion resistance, long life, low noise, high efficiency, suitable for ship sewage, pumping clean water, dirty water, raw water, pumping sea water for marine diesel engine heat exchanger cooling water circulating, pumping a variety of oil materials, fire pump and deck wash pump, etc.

Performance data:

Drive mode: V-Belt

Impeller diameter: mm

Equipped with power: 5kw/7.5hp

Suitable speed: 2850r/min

Flow: 40000 L/hour

Head: 30 meters

Suction: 7 meters

Power consumption: 5.5kw

installation screw hole: mm

Screw hole center distance: Length mm/Wide mm

Inlet and outlet: cast iron 80x65mm
