Marine Shangchai Weichai 6135CB 762D Double Stage Self priming Seawater Pump 135 Series Hanging Slurry Double Two Suction Four hole sea water cooling Pump

China shanghai diesel Marine engine 2 stage cooling sea water pump 6135 two stage impeller

Application:

6135Cab-1" Cast iron Marine diesel engine cooling sea water pump, double stage impellers,self-priming pump,it can be applied to Shangchai 6105, Shangchai 6135,Nanchai 6135 marine diesel engine heat exchanger cooling water circulating. Used for Shipping, Fishing boat, Shipbuilding, Engine host matching,Wash deck, Fire fighting, etc.

6135Cab-1" Cast iron Marine diesel engine cooling sea water pump is single stage impeller,single suction, cantilevered centrifugal pump, corrosion resistance, long life, low noise, high efficiency, suitable for ship sewage, pumping clean water, dirty water, raw water, pumping sea water for marine diesel engine heat exchanger cooling water circulating, pumping a variety of oil materials, fire pump and deck wash pump, etc.

Performance data:

Drive mode: V-Belt

Impeller diameter: 112mm

Equipped with power: 1.7kw/2.3hp

Suitable speed: 2850r/min

Flow: 5500 L/hour

Head: 15 meters

Suction: 2 meters

Power consumption: 0.92x2kw

installation screw hole: 13mm

Screw hole center distance: Length 122-123mm/Wide 77-78mm

Inlet and outlet: cast iron M34x2.5mm(center pitch 65mm)
