ECL-1A, Aluminum Japanese TSK Marine Double Romote Control Lever

Applications:
Marine twin remote control lever,Engine throttle control Switch shift, mainly applied for motorboats,fishing boats and other water home vehicles to control accelerator and gearshift.

1.Suitable for most boat/engine combinations, control throttle and shift of diesel or gasoline engines.
2.controls 1 engines, connect with 2 cables.
3.Throttle control is with locking device, can screw locking handle when moving at a constant speed, when accelerating or decelerating, unscrew the handle to enable it shake back and forth which allows micro-adjust accelerator or decelerator then control speed. Shift control is divided as front, middle and back shifts, can shift easily.
4. Zinc alloy housing, chrome plated, stainless steel as interior part material, waterproofing and anti-rusty with advanced structure.
5.Ergonomically designed, easy installation and operation, top mounting.
6.Combined with cable type 33C, can be any length within 23 meters.
7.Neutral Safety Switch as option to make start-in-gear protection.

Features:
Usually work for inboard engine
Ergonomically designed,work for one engine
Each separate lever controls shift or throttle
Functions easily identified by red and black knobs
Throttle control with locking device
Shift control divided as front,middle and back shifts
Each handle can be separate for throttle or shift function
Ideal for marine inboard engine and mixer truck

Material:
Housing part: Zinc alloy construction chrome plated
Interior part: stainless steel,Water proofing and anti-rusty

Suggested Connection cable systems:
Connect with 2 pieces 3300/33C type control cables
Cable length: within 23 meters
Cable stroke: 96mm
Pull force:1400N max
Push force:190N max

Product Picture:
